Dynacord L1300FD Digital Forstærker (2x650W, DSP)

(0)
🎧
Support online
Support 1 Support 2 Support 3
5.699 kr.
Gratis fragt
5.699 kr.

Beskrivelse

  • 1300W DSP forstærker
  • Kompakt og ideel til live/studie lyd på farten
  • True 2 Ohm stabilitet
  • FIR Driver teknologi
  • 'Et-knaps' DSP indstilling

Dynacord L1300FD Forstærker 2x650W og DSP

  • Proffesionel DSP forstærker ideel til live-, studie og på farten.
  • Kæmpe 1300W effekt med fantastisk lydperformance.
  • Fuldt integegreret Speaker rocessing med FIR driver teknologi.
  • Gennemført og stabil performance selv ved 2 ohm.
  • Nem og intuitivt 'et-knaps' DSP indstilling.
  • Med både balanceret XLR- ind og ud.
  • Måler: 483 x 88 x 462.4 mm
  • Vejer: 12.9 kg

Tekniske specifikationer

Load Impedance 2 Ω 2.6 Ω 4 Ω 8 Ω
Maximum Output Power, Single Channel 1100 W 950 W 660 W 350 W
Maximum Output Power, Dual Channel 1000 W 850 W 600 W 320 W
Maximum Output Power, Bridged - - 2000 W 1200 W



Maximum RMS Voltage Swing THD = 1%, 1 kHz 55.3 V
Voltage Gain Ref.1 kHz 32.0 dB
THD at 450 W/4 Ω MBW = 80 kHz, 1kHz < 0.05%
IMD-SMPTE, 60 Hz, 7 kHz < 0.1%
DIM30, 3.15 kHz, 15 kHz < 0.05%
Maximum Input Level +21 dBu
Crosstalk ref. 1 kHz, at 100W/4 Ω < -80 dB
Frequency Response, ref. 1 kHz 10 Hz to 21 kHz (±1 dB)
Input Impedance, Active Balanced 20 k Ω
Signal to Noise Ratio Amplifier, A-weighted, ref to Max. Output Power@ 8 Ω >104 Db
Output Noise, A-weighted < -68 dBu
Output Stage Topology Class AB
Power Requirements 240 V, 230 V, 120 V or 100 V; 50 Hz to 60 Hz (factory configured)
Power Consumption ⅛ MaximumOutput Power @ 4 Ω 550 W
Mains Fuse 240 V/230 V: T10AH; 120 V/100 V: T20AH
Protection Audio limiters, high temperature, DC, HF, Back-EMF, Peak current limiters, In rush current limiters, Turn on delay
Cooling Front-to-rear, 3-stage-fans
Ambient Temperature Limits +5°C to +40°C (40°F to +105°F)
Safety Class I
Color Black
Dimensions (W x H x D), mm 483 x 88 x 462.4
Weight 12.9 kg (28.4 lb)
Signal Processing FIR filters, audio limiters, output and array** delay, 10-band** user PEQ, 5-band array PEQ** per channel, load impedance
Remote Control SONICUE sound system software **
Accessories RMK15 (rear rack mount kit)

Brand: Dynacord
SKU: DYN-L1300FD
EAN: 8717332986675
Vægt: 13.0 kg
