Beskrivelse
Beskrivelse
- High-power LF supplement til TX2152
- Low-distortion port design
- Two high-excursion EVS-18S woofers
- Use with processor and dedicated amp channel
- 103 dB sensitivity, 138 dB max SPL
- Power handling: 1000 W continuous, 4000 W peak
- Mount points (6) for optional wheel kit
- Braced plywood/MDF enclosure
- High-power LF supplement to TX2152
- Low-distortion port design
- Two high-excursion EVS-18S woofers
- Use with processor and dedicated amp channel
- 103 dB sensitivity, 138 dB max SPL
- Power handling: 1000 W continuous, 4000 W peak
- Mount points (6) for optional wheel kit
- Braced plywood/MDF enclosure
- Black EVCoat? finish
Tekniske specifikationer
Tekniske specifikationer
| Color | Black |
| Input Connections | Parallel Neutrik® NL4 |
| Speaker Type | Subwoofer |
| Enclosed Material | Plywood and MDF with EVCOAT |
| Nominal Impedance (Passiv) | 4 Ω |
| Minimum Impedance | 2,9 Ω |
| Frequency Response (-3 dB) | 50 - 160 Hz |
| Frequency Response (-10 dB) | 40 - 1500 Hz |
| Internal Crossover | No |
| Max. SPL/1m (calc) | 138 dB |
| Recommended Low-Pass Frequency | 80 - 120 Hz |
| Sensitivity 1W/1m | 103 dB |
| LF Transducer | (Two 18 inch EVS18S |
| Height | 1154 mm (45.43") |
| Width | 508 mm (20") |
| Depth | 691 mm (27.2") |
| Weight Net | 56,1 kg |
